OLIGHT3L-F OTSUKA

OLIGHT3L-F

■Product features
The OLIGHT3L-F-F features a diagonally-mounted white LED lighting panel to emit light at an angle in relation to the lens center. This means the product is designed with an emphasis on rendering unevenness on work-pieces visible. The model excels at detecting surface scratches and dents, etc. on metal and resin. The rectangular lens has reduced peripheral distortion to handle extended work periods. The product can reduce strain and fatigue from work through the use of optional AR-Coated Lenses which suppress refraction, increasing the volume of light that passes through.

■Product Name
LED illuminated magnifier

■Model
OLIGHT3L-F (Free arm-type illuminated magnifier)

■Product Specifications

Lens spec	Free arm-type
Magnification	2x 3.5x
Lens dimension (mm)	144×108
Effective lens dimension (mm)	139×103
Lens Material	Optical glass
Working distance (mm)	2x/160, 3.5x/120
Lens weight (g)	2x/560, 3.5x/730
Lens system	Recta-lens system
AR Coating options	Available / 2x 3.5x
Lighting
Light source	LED light panel
Power Supply Voltage	100～240V, 50/60Hz, plug type A * It is usable 125 ～ 240V by changing the cord with attached AC plug.For more information, please contact your distributor.
Power consumption	9W
Standby power	0W
Dimming Function	Available / adjustment range 100～50%
Body
Product weight	OLIGHT3L 2x (approx. 3.0Kg) O-LIGHT III-L 3.5x (approx. 3.3Kg)
Arm length (mm)	1000
Head Dimensions (mm)	293×205
clampable width (mm)	15～60
Operating temperature range	5℃ ～40℃
Dustproof and waterproof protection grade	IP20 (indoor use only)
