| Ordering data |
|
| Product type description |
ACTUATOR AZ/AZM 415-B30-05 |
| Article number (order number) |
101139957 |
| EAN (European Article Number) |
4.03066E+12 |
| eCl@ss number, version 12.0 |
27-27-26-06 |
| eCl@ss number, version 11.0 |
27-27-26-06 |
| eCl@ss number, version 9.0 |
27-27-26-06 |
| ETIM number, version 7.0 |
EC001487 |
| ETIM number, version 6.0 |
EC001487 |
| |
|
| General data |
|
| Enclosure material |
Light-alloy diecast, paint finish |
| Material of the actuator |
Zinc die-cast |
| Material of the operators |
Aluminium |
| Emergency exit material |
Metal, plastic-coated |
| Gross weight |
1,060 g |
| |
|
| General data - Features |
|
| Emergency handle |
Yes |
| |
|
| Mechanical data |
|
| Door hinge |
Right |
| Shearing force |
25,000 N |
| Actuator mounted |
Outside |
| |
|
| Mechanical data - Dimensions |
|
| Length of the actuator |
90 mm |
| Width of the actuator |
157 mm |
| Height of the actuator |
105 mm |
| Length of the emergency exit |
34 mm |
| Width of the emergency exit |
75 mm |
| Height of the emergency exit |
55 mm |
| |
|
| |
|
| Schmersal Canada Ltd., 29 Centennial Road, Unit 1, Orangeville, Ontario L9W 1R1 Canada |
| The details and data referred to have been carefully checked. Images may diverge from original. Further technical data can be found in the manual. Technical amendments and errors possible. |
