Features of S6061-08DFK DK On/off Rapid Running Damper Actuator

Technical datasheet of S6061-08/16 DK On/off Rapid Running Damper Actuator

Item	Unit	S6061-08DFK	S6061-16DFK	S6061-08DNK	S6061-16DNK
Torque	Nm	8	16	8	16
Damper area	m2	2	4	2	4
Running time	sec	8	16	8	16
Power supply	V	24VAC/DC；230VAC；110VAC
Frequency	Hz	50/60Hz7.5W 50/60Hz
Running consumption	W	7.5W（24V）；10.5W（230V）
Maintaining consumption	W	0.5W（24V）；2.5W（230V）
Weight	Kg	1.25kg
Control signal		2/3 point
Rotation angle		0~90º（Max 93°）
Limited angle		5~85º（Per step 5º）
Auxiliary switch rating		3（1.5）Amp 250V
Life cycle		>70000 cycles
Noise level		45dB(A)
Electrical level		Ⅱ
Protection level		IP44 or IP54
Temperature		-20~+50℃
Humidity		5~95%RH
Storage temperature		-40~+70℃
Certificate		CE UL（Except 230V）

Remark: After lead out the Actuator wire by PG joint, the IP Protection can reach IP54.

Wiring Diagram of S6061-08/16 DK On/off Rapid Running Damper Actuator

s6061-08-16-dk-on-off-rapid-running-damper-actuator-3

S6061-(08、16)DK damper actuator can be controlled by 2/3 point.

DFK Auxiliary switch of S6061-08/16 DK On/off Rapid Running Damper Actuator

There are two auxiliary switches of S6061-(08、16) DFK damper actuator, can set the angle 0-90° (factory sets 10° and 80°), it will show a signal when the actuator turns to the setting angle.

s6061-08-16-dk-on-off-rapid-running-damper-actuator-4

Angle of rotation limiting of S6061-08/16 DK On/off Rapid Running Damper Actuator

s6061-08-16-dk-on-off-rapid-running-damper-actuator-5

The rotation angle or working range of the actuator can be adjusted 5°by adapter so that can limit mechanically. You just press the locking clip to lose the adapter.
