Economic Single Mast Stacker CDY10S 1000KG

Economic Single Mast Stacker CDY10S 1000KG

Economic Single Mast Stacker CDY10S



Capacity:1000kg,Lifting Height:1600-1950mm

1.Separately excited motor,strong climbing ability

2.High strength forks

3.Built-in charger

4.Automatic lifting limit,motor and battery life extension

5.Stepless speed control system,safe and quite.

6.Controller with multiple automatic protection

7.Emergency reversing device.

Model   CDY10S
Mast type   Single stage
Load capacity kg 1000
Load center mm 600
Wheel base mm 1052
Operating type   Walkie
Wheels
Wheels type   PU
Wheel quantity    2001/1/4
Driving wheel/Balance
wheel/Bearing wheel
Dimension
Standard lift height mm 1600/1950
Max extend height mm 1985/2335
Mast lowered height mm 2065/2240
Lowered fork height mm 90
Fork size(length/width/ mm 1150（1220）/185/55
thickness)
Overall length mm 1634
Overall width mm 790
Outside width between mm 550/600/650/685
forks
Inside width between mm 180/230/280/315
forks
Min.Turning radius mm 1262
Min.Aisle width for pallets 800×1200 mm 1841
Min.Aisle width for pallets 1000×1200 mm 1883
Min.ground clearance mm 30
Performance
Travel speed,laden/ km/h 3/3.5
unladen
Lift speed,laden/unladen mm/s 130/230
Lowering speed,laden/ mm/s 130/230
unladen
Gradeability,laden/ % 5/7
unladen
Electrical configuration
Drive motor/Lift motor/ KW DC0.63/DC2.0
Steering motor
Battery voltage V 24
Battery capacity Ah 70
Brake   Electromagnetic
Weight
Battery weight kg 48
Service weight with kg 460
